Cell Hardware

Single Cell Hardware

$4,499

Our Single Cell Hardware represents the gold standard in electrolyzer cell design. Manufactured with precision-machined components and high-grade materials, this hardware enables researchers to conduct detailed single-cell studies with exceptional accuracy and reproducibility. The modular design allows for easy assembly and disassembly, facilitating rapid testing of different membrane electrode assemblies and operating conditions.

Specifications
Active Area25 cm²
Cell MaterialTitanium Grade 2
Gasket MaterialPTFE/Viton composite
Operating PressureUp to 30 bar
Operating TemperatureUp to 80°C
Current DensityUp to 4 A/cm²
Flow FieldSerpentine design
Connections1/4" NPT fittings
Dimensions15 x 15 x 8 cm
Weight2.5 kg
Key Features
  • Precision-machined titanium construction
  • Optimized flow field design
  • Easy assembly/disassembly
  • High-temperature compatibility
  • Corrosion-resistant materials
  • Standardized connections
  • Research-grade precision
Applications
  • Single cell testing
  • MEA characterization
  • Performance optimization
  • Research and development
  • Educational purposes
